Wood Veneer Crushing Machines
except for wood veneer dryer , the wood chipper can also be used in other field of woodworking filed. it is very high efficiency chipping machines.
Price
$13,000.00
Product Details
Wood Veneer Crushing Machines
Wood chipping machine is one of the normally used machines in wood working field . it is used to chip the wood pieces, wood blocks and other waste wood into small pieces. The wood chippers machine can be used together with shine roller veneer dryer and biomass buner . as the wood chips size of the biomass burner can not be so big size . the wood chipper can chip the waste wood into pieces about size 3-4cm. except for wood veneer dryer , the wood chipper can also be used in other field of woodworking filed. it is very high efficiency chipping machines.
Model | BX216 |
Input conveyor length(m) | 6 |
Output conveyor length(m) | 11 |
Tool roll diameter(mm) | 600 |
Feed port size(mm) | 230*500 |
Flying knife number | 2pc |
Tool roll speed (r/m) | 590 |
Maximum diameter of processing raw material(mm) | 230 |
Feeding speed(m/min ) | 35 |
Wood chips size(mm) | 30 |
Capacity(ton/h) | 7-8 |
Main motor power(kw) | 55 |
Feed roller motor power(kw) | 3-4 |
Oil pump motor power(kw) | 1.5*1 |
Weight(kg) | 4070 |
Overall size(mm) | 2600*1900*1210 |
Conveyer motor power(kw) | 3 |
Company Profile
Shandong Shine Machinery Co., Ltd. is a large-scale enterprise specializing in R&D and production of veneer rotary cutting and veneer dryer equipment. Since its inception, the company has been adhering to the vision of “making first-class corporate contributions, building first-rate enterprise talent, creating first-class corporate brand,implementing modern enterprise management system, using new sales concepts and service systems, and investing 10 million yuan in scientific research each year. It also combine industrial universities to study high-end technology, so that Shine's veneer dryer products are always at the forefront of the industry's technology. Shine roller veneer dryer products are sold to various provinces and cities in the country, and exported to Russia, South Africa, Southeast Asia and many other countries and regions.
Our Services
Pre-sale services:
1) Provide the free consultation of all Core Veneer Dryer Machine
2) According to the clients' special requirement, offering the reasonable plan and free design to help to select the equipment.
3) Welcome to visit our factory
Services during the sales:
1) Inspect the machine before leaving the factory.
2) Oversea install and debug the equipment
3) Train the first-line operator.
After sale services:
1) 24 hours online service
2) Provide the VIDEO with Install and debug the equipment
3) Provide technical exchanging
4) Door to door service is possible
