Latvia Second Sets 4-Deck Roller Veneer Dryer
(1)Low maintenance is required for Shine veneer dryer and no veneer jamming can reduce downtime.
(2)We have professional R&D team which can design different models as customers’ requirement.
(3)The veneer after drying is free of splits/cracks and in good condition for gluing/bonding.
Product Details
Product Introduction of 4-Deck 36m Wood Veneer Dryer Machine
4-Deck 36m Roller Veneer Dryer is the second set of Dryer bought by Latvia customer.While ensuring production capacity, the upgraded equipment fan has decreased from 11 kW to 5.5 kW, resulting in a decrease of over 35% in the overall machine.We have learned that the customer has a demand for drying 1.5 meters wide veneers, and we have proposed a personalized plan to increase the working width from 3 meters to 3.5 meters,reducing the probability of board jamming and gaining the customer's recognition.Shine Machinery always adheres to technological innovation, continuously improves user experience, and has won the favor of users.
Product Parameters of 36 m Wood Veneer Dryer Machine
Model No | GTH35-36 |
Working Width | 3.5m |
Deck | 4 |
Heating area length | 32m |
Cooling area length | 4m |
Veneer thickness and size | 0.8-8mm |
Veneer water moisture | Fresh veneer to about 8-10% |
Heating material & drying temperature | Waste wood, 140-200°C adjustable. Temperature control accuracy ±5°C. There is automatic temperature control and speed regulation system, which can guarantee the moisture content is consistent. |
Drying capacity (m³/day) | Around 130 m³ |
Veneer transport speed | 5-22m/min，16A chain |
Hot air blower | Power: 4KW（32pc） |
Traction motor | Power: KW，5.5frequency control（4pc） |
Cold air blower | Power: 4KW（4pc） |
Air intake fan | Power: 11KW（2pc） |
15 ton biomass burner | Power: 16.5KW |
Total power | 204.5 KW |
Actual electricity consumption | About 140kwh per hour |
Certificate
Transportation
Our Serivce
1.According to the clients' special requirement, offering the reasonable plan and free design to help to select the equipment.
2.Welcome to visit our factory.
3.Inspect the machine before leaving the factory.
4.Oversea install and debug the equipment.
5.Train the first-line operator.
6.Provide the VIDEO with Install and debug the equipment.
7.Provide technical exchanging.
8.Door to door service is possible.
