2-Deck 44m Roller Veneer Dryer
Working width is flexible.It can be customized according to customer's drying output and veneer's size.
The biomass burner is equipped with a rotating grate and blower, which can directly burn wet bark. The temperature inside the Biomass Burner can reach about 800 degrees Celsius, providing sufficient heat for veneer drying.
Product Details
Product Introduction of 2-Deck 44m Wood Veneer Dryer Machine
2-Deck 44m Wood Veneer Dryer adops 3.75m working width which can dry about 85cubic meters in 24 hours.It is equipped with a 6-ton Biomass Burner, which can provide 3.6 million calories of heat to the dryer, ensuring that you can achieve the desired drying output and moisture content.Although our biomass burner is currently the lowest cost heat source for drying, we also provide customers with multiple options. Customers can choose thermal oil, steam, etc. as heat sources, and we can replace the corresponding heat exchanger.
Product Parameters of 44 m Wood Veneer Dryer Machine
Model No | GTH375-44 |
Working Width | 3.75m |
Deck | 2 |
Heating area length | 40m |
Cooling area length | 4m |
Veneer thickness and size | 0.8-8mm |
Veneer water moisture | Fresh veneer to about 8-10% |
Heating material & drying temperature | Waste wood, 140-200°C adjustable. Temperature control accuracy ±5°C. There is automatic temperature control and speed regulation system, which can guarantee the moisture content is consistent. |
Drying capacity (m³/day) | Around 85 m³ |
Veneer transport speed | 5-22m/min，16A chain |
Hot air blower | Power: 5.5KW（10pc） |
Traction motor | Power:7.5 KW，frequency control（2pc） |
Cold air blower | Power: 5.5KW（1pc） |
Air intake fan | Power: 11KW（2pc） |
6 ton biomass burner | Power: 16.5KW |
Total power | 114KW |
Actual electricity consumption | About 80kwh per hour |
Certificate
Transportation
Our Serivce
1.According to the clients' special requirement, offering the reasonable plan and free design to help to select the equipment.
2.Welcome to visit our factory.
3.Inspect the machine before leaving the factory.
4.Oversea install and debug the equipment.
5.Train the first-line operator.
6.Provide the VIDEO with Install and debug the equipment.
7.Provide technical exchanging.
8.Door to door service is possible.
